Feature:
Supports Daterate up to 155Mbps
Duplex LC connector
SFP duplex wavelength: 850nm,1310nm ,1490nm ,1550nm
Applicable for 550m~80Km connection Digital Diagnostic Monitor Interface
Operating case temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C
Application: Ethernet /Fiber Channel/Switch to Switch interface/Router/Server interface/Other optical transmission systems;
SFP 155M Duplex - table
Package | Part number | Fiber | Data Rate | Wavelength | Source | Distance | Temperature | DDM |
SFP | SD1S-M85VP-02 | MMF | 155Mbps | 850nm | VCSEL/PIN | 2km | 0~70°/-40~85° | √ |
SFP | SD1S-M31FP-02 | MMF | 155Mbps | 1310nm | FP/PIN | 2km | 0~70°/-40~85° | √ |
SFP | SD1S-S31FP-02 | SMF | 155Mbps | 1310nm | FP/PIN | 2km | 0~70°/-40~85° | √ |
SFP | SD1S-S31FP-20 | SMF | 155Mbps | 1310nm | FP/PIN | 20km | 0~70°/-40~85° | √ |
SFP | SD1S-S31DP-40 | SMF | 155Mbps | 1310nm | DFB/PIN | 40km | 0~70°/-40~85° | √ |
SFP | SD1S-S31DP-60 | SMF | 155Mbps | 1310nm | DFB/PIN | 60km | 0~70°/-40~85° | √ |
SFP | SD1S-S55DP-80 | SMF | 155Mbps | 1550nm | DFB/PIN | 80km | 0~70°/-40~85° | √ |
SFP | SD1S-S55DP-100 | SMF | 155Mbps | 13550nm | DFB/PIN | 100km | 0~70°/-40~85° | √ |
SFP | SD1S-S55DP-120 | SMF | 155Mbps | 1310nm | DFB/PIN | 120km | 0~70°/-40~85° | √ |
