Features:
3.3V or 5Vpower supply VCSEL/FP Laser Diode Transmitter
Up to 2 Km on 62.5/125um MMF Up to 40 Km on 9/125um SMF
3.3V or 5Vpower supply
SC/ST/FC duplex optical interface (LV)TTL Input /Output and LVTTL signal detect
Class 1 Laser International Safety Standard IEC825 Compliant
Operating case temperature range (Standard: 0 to+70°C) Or (industrial: -40°C to +85°C)
Application: RS232/RS485/RS422 receptacle fiber transmission / Other optic link
1X9 Duplex 60K-60M - Table
Package | Part number | Data Rate | Wavelength | Fiber | Source | Reach | Connector | Temperature |
1x9 | 8TR-109ST | 64K-60M | 850nm | MMF | FP/PIN | 2 | FC/SC/ST | 0~70° / -40~85° |
1x9 | 8TR-110ST | 64K-60M | 1310nm | MMF | FP/PIN | 2 | FC/SC/ST | 0~70° / -40~85° |
1x9 | 8TR-111ST | 64K-60M | 1310nm | SMF | FP/PIN | 40 | FC/SC/ST | 0~70° / -40~85° |
